Features

• Double walled with PUF insulation
• Interior & Exterior SS 304. Interior is provided with mirror finish
• Stainless Steel trays
• Full-length inner glass door, metal door with gasket & lock on the outside
• Forced air circulation for uniform temperature
• PU wheels for easy movement
• Fluorescent tube light fitted in the centre of the chamber to provide illumination & produce visible light measured in lux
• UV light of wavelength 365nm (measured in watt/sq. m.) fitted on top of the chamber
• U-shaped SS tubular heaters
• CFC free cooling system consisting of hermetically sealed compressor coupled with evaporation coil & condenser
• (Optional )Complete Operations driven through PLC with data logging capacity of upto 1000 readings & email facility • High speed Ethernet based communication
• All operations through a single Colour Touch Screen(optional)
• PT-100 Temperature sensor/thermocouple
• Safety devices: Low & high temperature cut-off settable thermostats
• Safety thermostat switches off the lights upon temperature overshoot.
• Automatic switch off of UV lights upon door opening
• Audio/Visual alarms for deviations
• Complete with DQ, IQ, OQ, PQ (optional) & SOP & Maintenance Manual Photostability chambers are specifically designed to perform near UV and visual light testing with fluorescent lamps per ICH Q1B Guidelines, Option 2. This unit controls light and temperature conditions through an easy-to-use colour touch-screen interface. Uniform light distribution and high intensity levels allow quick response for forced degradation testing and confirmatory studies. The confirmatory studies should identify precautionary measures needed in manufacturing or in formulation of the product, and if light resistant packaging is needed. At the end of the exposure period, the samples should be examined for any changes in physical properties (e.g., appearance, clarity, or colour of solution) and for assay degradation. Optional -chambers are fully controlled via the PLC with features such as alarms for aging lamps, auto-switch off of UV lights upon door opening. Additionally, the chamber also provides precise humidity control. Inbulter floor lavel indicator
